Granular Activated Carbon Filter (GAC)

Granular Activated Carbon remove odor and color by straight-flow diffusion

Filter Media: Granular Activated Carbon

End Cap: Polypropylene

Operating Conditions

・ Maximum Operating Temperature: 40°F-140°F (5°C-60°C)

・ Recommended Flow Rate: 1 GPM per 10” length

・ Recommended Change Out Differential Pressure: 35 psid (2.4 bar)

Product Specification

・ Out Diameter: 2.67” (68mm)

・ Length: 10", 20", 30", 40"

・ Retention Rating: 5 µm

Notes

1. The drinking water of unknown quality may require proper disinfection or pre-treatment in addiction to carbon filtration.
2. CB-B and CB-WS series container a very small amount of carbon fines. After installation, please flush the cartridge for a minimum of 5 minutes to remove all traces of carbon prior to using them in the process. Use the tap water to flush the cartridge for at least 20 seconds prior using for drinking water or cooking purposes.
3. Steps should be taken to prevent the filter cartridge from freezing. This may affect cartridge performance.
